Medicine Trough Type Powder Mixer
description
Junzhuo Single Arm Mixers are suitable for mixed powder or paste material in pharmaceutical, chemical, food and other industries.
Characteristics
Through the mechanical transmission, CH mixers offer durable, reliable and more efficient mixing.
parameter:
Model | Max Loading Volume | Operation Volume | Rotatio Speed | Motor Power | Discharge Motor Power | Discharge Angle | Overall Dimension | Approx Weight |
CH-1 | 1.3L | 1L | 24rpm | 0.2kw | By Manual | 120 | 430*220* | 30kg |
CH-30 | 33L | 30L | 24rpm | 0.75 | 360 | 1020*420*600 | 120kg | |
CH-50 | 55L | 50L | 24rpm | 1.1kw | 360 | 1050*500*800 | 200kg | |
CH-100 | 110L | 100L | 24rpm | 3kw | 0.55kw | 360 | 1400*500*1000 | 350kg |
CH-150 | 170L | 150L | 24rpm | 4kw | 0.75kw | 360 | 1660*600*995 | 600kg |
CH-200 | 220L | 200L | 24rpm | 5.5kw | 0.75kw | 360 | 1660*600*995 | 620kg |
CH-300 | 320L | 300L | 22rpm | 5.5kw | 1.1kw | 360 | 2200*680*1100 | 800kg |
CH-400 | 420L | 400L | 22rpm | 7.5kw | 1.5kw | 360 | 2400*710*1200 | 850kg |
CH-500 | 525L | 500L | 24rpm | 11kw | 2.2kw | 360 | 2400*850*1260 | 920kg |
CH-1000 | 1050L | 1000L | 18rpm | 18.5-22KW | 3kw | 360 | 3150*1000*1500 | 2100kg |
