Semi-Automatic Capsule Filler
Product Description of Capsule Filler
It adopts electrical equipment and air control device to control each other, and Equipped with an electric automatic device counting device to complete the capsule positioning, separation, filling and
locking process, which can improve productivity and reduce labor. The whole process complies with GMP standards.
The machine runs smoothly, the filling dose is accurate, the structure is novel, and the operation is convenient.
Working Principle of Capsule Filler
During operation, the gear drive drives the turntable to rotate, the capsule is selected/sent into the die hole, and the upper and lower parts of the capsule are separated. The fill rod then pushes the grain or
material into the capsule and closes/pushes out; the waste reject column then rejects the unsaturated capsules and sucks them out.
Product Show of Capsule Filler
Characteristics of Capsule Filler
1. High-capacity, high-definition recordable information, in line with CGMP, FDA certification
2. The linear bearings imported from Japan are used to ensure the long service life of the machine and the high precision of the machine
3. The worktable cam runs under good lubrication conditions, and fully maintains the internal lubrication of the cam groove, which increases the service life of the pressure crusher oil pump and extends the service life of the parts. Lip seal provides better sealing performance
4. Using PLC and touch screen control, stepless variable frequency motor, all parameters can be set on the touch screen, the operation is very convenient
5. Three-dimensional adjustment of the metering plate, uniform space to ensure accurate filling, the capsule yield can reach 99%
Parameter of Capsule Filler
JTJ-V Semi-Automatic Capsule Filling Machine | |
Model | SED-250J |
Capacity | 15000caps/h |
Type of filling materials | Powder/Pellets |
Capsule Size | 000#-5# and safety capsule |
Power | 380/220V 50/60Hz 2.2KW |
Dimensions | 1650*860*1780mm |
Net Weight | 500KG |
Locking Device | Automatic |
Product Details of Capsule Filler
Application of Capsule Filler
This machine is our latest upgraded generation of special equipment for pharmaceutical products. Materials in powder, granule or granular form can be filled.
The specially designed double-head capsule seeding device adopts an automatic servo motor system, and the capsules are automatically separated after sowing. Triple capacity to 36,000 grains/hour.
