Water-soluble tablet film coating machine
Product Description of Tablet Film Coating Machine
In the film coating operation of the host, the water-soluble film coating machine has the characteristics of dust-free flying, syrup splashing, improved operating conditions, less tablet cross-contamination, simple coating process, short coating time, and high production efficiency.
It is used to coat organic film, water-soluble film and sugar film on various tablets, pills and bubble gum. It has the characteristics of high efficiency, low energy consumption and small footprint. It can be widely used in the fields of pharmacy, food and biopharmaceuticals, coating various tablets, pills and candy with organic film, water-soluble film and sugar film.
Configuration Features of Tablet Film Coating Machine
1. Different parts of the host are equipped with multiple sprinklers to clean the coating machine online;
2. Equipped with an independent cleaning liquid pressurization and distribution station to ensure that the pressure of the cleaning liquid injected from each spray head reaches a certain value, and the coating machine can be effectively washed;
3. It is equipped with a circulating cleaning and drainage system that can be selected by the cleaning program;
4. Under the control of PLC, multiple cleaning programs can be programmed, and the residual water of each sprinkler head is flushed with compressed air, which can realize the automatic cleaning and drying process.
Machine Parameters of Tablet Film Coating Machine
Technical parameters | |
Item | BG-5E |
Diameter of coating drum | φ564 φ510 φ420 |
Coating pan Capacity | 5 kg 3 kg 1 kg |
Rotate speed of drum (R/Min) | 0-30r.p.m |
Power of main motor | 0.37kw |
Power of air exhaust tank motor | 0.55kw |
Air flow of air exhaust tank | 805m3/h |
Power of hot air tank motor | 0.25KW |
Air flow of hot air tank | 504m3/h |
Equipment Size | 1250×900×1700 |
Net Weight | 750 kg |
Feature of Tablet FilmCoating Machine
1. Using the PLC module, you can set all operations, such as hot air temperature setting and control, drum adjustment and rotation, automatic control and negative pressure display, and other movie interfaces with just one touch of the touch key on the completely sealed computer control panel.
2. The machine can be cleaned freely, with reliable and stable performance. The streamlined guided mixer can drive the tablets so that the tablets rotate easily and smoothly without chipping and edge chipping, thereby increasing the output. The guide sheet has a narrow surface, which cannot adhere to the dressing, thereby saving dressing and improving the quality of the finished product.
3. The constant pressure variable track pump has the rotating radius of the pressure roller, the output syrup volume and the spray syrup volume are automatically controlled, the atomization is stable, the spray system is simplified, the dressing is saved, and it is easy to fully clean.
4. Special imported prayer gun, simple operation and control process requirements, uniform density, particle size, uniform atomization, large spray area, adjustable flow, no leakage, no blockage, no angle, no fan shape. The spray gun can be used until its head remains in the range of 0.29Mpa to 0.39Mpa. So far, it has been well received by users at home and abroad.
Product Show of Tablet Film Coating Machine
Scope of Application
The coating machine is mainly used for the production of sugar coating of pills and tablets in the pharmaceutical industry, and can also be used for rolling, mixing and polishing of spherical or granular materials in the food, light industry and chemical industries. For example: chocolate polishing,
wrapping peanuts, sugaring, seasoning, making glutinous rice balls, pearl powder balls, rolling desiccant, producing chemical fillers, aluminum hydroxide balls, alumina balls, ceramic ball molecular sieves, catalysts.
