Vegetable Fruit Plant Vacuum Drying Machine
Product Description of Vacuum Drying Machine
Under boiling conditions, pure water has the highest evaporation rate. Under normal pressure, pure water starts to boil at 100°C under vacuum, because the vapor pressure in the system is lower than the vapor pressure on the surface of the material, and the boiling point of water is below 100°C, for example.
When the surface is 0.07MPa, water will boil at 70°C, the higher the vacuum pressure, the lower the boiling point. In the vacuum dryer, the evaporated water can be quickly removed by the vacuum system. Therefore, although the dryer is at a lower working temperature, it has a greater drying capacity.
During the operation of the equipment, the material is in a static condition, which helps to maintain the initial state of the material. Intermittent operation can adjust the process conditions at any time.
On the top of the FZG series dryer, a heating system is installed to solve the problem of condensate backflow. In addition, an air suction device is installed on the side to improve drying efficiency.
This equipment can be used for low-temperature drying and solvent recovery. The heat source can be steam, hot water or heat transfer oil.
It is especially suitable for materials that are easily oxidized during the drying process.
Show of Vacuum Drying Machine
Machine Parameters of Vacuum Drying Machine
Power(W) | 5.5kw | Key Selling Points | Energy saving |
Dimension(L*W*H) | 1380*1200*2000 | Weight | 500kg |
Interval(mm) | 122 | Item | 51 |
Type | Vacuum Drying Equipment | Working pressure | Less than 0.4 |
Main Feature of Vacuum Drying Machine
It can get higher drying speed at lower temperature and the heat energy can be used fully.
It can dry at low temperature or can dry heat sensitive raw materials.
It can dry raw materials that contain solvent and the solvent needs to recover.
Before drying, it can carry out disinfectant treatment. During the period of drying, any impurity can't enter in it. The dryer belongs to static vacuum one, the shape and volume of raw materials can't be damaged.
