The oral liquid filling machine is suitable for small batch production of small and medium-sized enterprises such as hospital preparation rooms, pharmaceutical factories, beverage factories, daily chemical plants, laboratories, etc. There are many materials that can be filled. The oral liquid filling machine uses electric, Fully automatic quantitative liquid dispensing machine with crank, mature technology and piston structure design, the equipment is suitable for hospital preparation rooms, ampoules, eye drops, various oral liquids, vials, pesticide bottles, special-shaped bottles of shampoo and various water preparations It can also be used for quantitative continuous filling of various liquids in various chemical analysis tests, especially for liquid sub-packaging in large, medium and small pesticide plants.
The oral liquid filling machine is one of the main components of the oral liquid washing, drying, filling and rolling linkage unit, which can be connected or used alone. The oral liquid filling machine mainly has the following working principles and components.
1. Transmission part:
The motor transmits the power to the worm gear shaft of the reducer through the pulley, and then the worm gear shaft transmits the power to the dial shaft, the filling part and the capping head through each gear. The filling part, the capping head and each dial move synchronously, and the power is transmitted to the bottle feeding dial device through the bevel gear.
2. Filling principle:
The oral liquid bottle is sent from the bottle feeding large dial to the transition dial, and then sent to the synchronous belt by the transition dial, and the bottle is dragged by the insert on the synchronous belt to run forward at a constant speed, and the filling needle is tracking Under the control of the mechanism, it is inserted into the bottle mouth and runs forward synchronously with the bottle to realize tracking filling. The submerged needle rises with the rise of the liquid level and plays a role in defoaming.
3. Cap supplying system:
It is composed of cap feeding track, cap management head and cap wearing mechanism. The capping head uses the principle of electromagnetic spiral oscillation to straighten the messy caps and enter the cap feeding track through the reversing twist channel.
4. Capping head:
After the oral liquid bottle is put on the cap and enters the capping head turntable, the three open knives will take the bottle as the center, rotate forward with the turntable, and press the cap under the control of the cam. Under the action of the tapered sleeve, the rolling knife rolls towards the cover at the same time, and after rolling, it leaves the cover at the same time and returns to its original position.
5. Tracking filling mechanism:
The equipment is driven by the servo motor to drive the gear and rack movement, thereby driving the filling needle to reciprocate. By adjusting the relative position of the needle holder and the mounting frame, the filling needle can be inserted into the middle of the bottle mouth accurately.
For a mature technical system, the oral liquid filling machine has a wide range of development space. Only when the technology is mature can we gain a firm foothold in the market. We should also comply with the requirements of the market and continuously improve the equipment to become more in line with customer needs. If you continue to pay attention to us about the remaining parts of this equipment, you can also inquire, we will create a fully automatic filling machine that truly meets your production requirements, and look forward to working with your company. cooperate.
