The SED-35LFK-B is a vertical continuous heat sealer for compatible plastic and laminated bags. The operator guides the flattened bag mouth into the sealing bands while a conveyor supports the bag. Heating and circulating-water cooling take place as the package moves through the machine.
Send Inquiry
Chat Now
Description

Hangzhou Shengde Machinery Co., Ltd. is one of the most professional manufacturers and suppliers of heat sealing machine for plastic bags in China. Welcome to wholesale customized heat sealing machine for plastic bags at competitive price from our factory. Contact us for cheap products and discount information.



Products Description

The SED-35LFK-B closes the open mouths of compatible plastic and laminated bags on a packaging line. Its raised sealing head works above a conveyor, allowing the package to remain upright as it passes through the machine. The conveyor carries the body of the bag while the sealing bands guide its mouth through the heating and cooling sections.

Presenting the bag mouth

The operator flattens the open edges of the filled bag and feeds them into the gripping and conveying bands. The bag then travels along the conveyor from right to left. As it moves through the sealing head, the film edges are held together and the seam is formed along the mouth. Bags can be presented in succession to maintain the continuous flow through the sealing section.

Heating the film and cooling the seam

The heated section transfers heat through the sealing bands to the film. These bands separate the bag surface from the heating plates and provide the moving contact surface through the sealing head. The heating arrangement and the documented operating range are identified in the parameter table.

After heating, the seam passes through the cooling section. Circulating water removes heat from this section so that the joined film is cooled as the package continues along the conveyor. Heating and cooling are part of the same pass through the machine, and the bag leaves the sealing head after travelling through both sections.

Setting up the head and conveyor

The sealing head can be raised or lowered to meet the bag mouth. A handwheel provides the adjustment, allowing the head to be positioned for the package being handled. The conveyor supports the bag beneath it. The listed conveyor dimensions and the sealing-height range are kept together in the specification table for checking the proposed line arrangement.

The control panel provides access to the operating controls. The heating setting and the conveying speed are selected for the film and the intended seam. During setup, the bag mouth must enter the bands evenly while the conveyor carries the filled portion along the sealing path.

Compatible packaging applications

The machine handles thicker plastic bags and compatible laminated packaging. Its applications include bag-closing operations in food, pharmaceutical, chemical, feed and fertilizer packaging. The listed film constructions identify the documented material range; suitability for a particular bag depends on its construction and the sealing conditions used.

The machine is intended to work alongside a conveying line. The operator presents each bag mouth to the sealing head, and the moving package passes through the heating and cooling stages before discharge. The documented unit dimensions and the separately listed conveyor dimensions should both be considered when arranging space for the equipment.

Products Specification
Parameter Specification
Model SED-35LFK-B
Equipment type Vertical continuous heat sealer
Compatible films Thicker PE film, PE composite film, aluminum-plastic laminate, paper-plastic laminate and woven bags with a PE film liner
Power supply 220 V, 50 Hz
Listed power 2 kW
Heating arrangement 2 constant-temperature heating modules
Control method Switching control
Temperature control range Ambient temperature to 400 °C
Cooling method Circulating-water cooling
Sealing speed 2–35 m/min
Seal width 8 mm
Sealing height above floor 640–1100 mm
Head-height adjustment Handwheel
Conveyor dimensions Approximately 1900 mm long × 300 mm wide
Listed unit dimensions Approximately 900 × 650 × 1450 mm (L × W × H); conveyor dimensions are listed separately
Listed machine weight Approximately 100 kg
Machine construction 304 stainless steel
Sealing bands Heat-resistant PTFE bands
Features
  • A raised sealing head closes bags as they travel upright on a conveyor.
  • Gripping and conveying bands guide the flattened bag mouth through the head.
  • The film passes through heating and cooling sections during the same run.
  • The sealing head can be positioned to meet the bag mouth.
  • The machine supports continuous bag-closing operations alongside a conveying line.
