How To Choose The Right Capsule Filling Machine For Your Pharmaceutical Production

Understand the working principle and types of capsule filling machines

How does the capsule filling machine work?

The capsule filling machine is mainly composed of multiple stations such as sowing, sorting, filling, rejecting, locking, and discharging. When in operation, it will first separate the capsule body from the capsule cap, then accurately fill the prescribed dose of powder or granules into the capsule body, and then re-lock the capsule cap and the capsule body. Despite the differences, all types of capsule filling machines operate on the same basic principle.

Types of Capsule Filling Machines

Capsule filling machines are mainly divided into two types: semi-automatic capsule filling machines and fully automatic capsule filling machines.

Semi-Automatic Capsule Filling Machines:

Semi-automatic capsule filling machine requires manual movement of the capsule tray from the capsule sowing station to the filling station. After filling, the capsule tray is manually moved to the capsule locking station and the capsule locking switch is pressed to lock and unload the capsule.

Features: easy to operate, can handle a larger production volume than manual machines, improve production efficiency, suitable for small and medium-sized enterprises.

Fully Automatic Capsule Filling Machines:

By automating the entire process of capsule placement, filling, rejection, and latching of the capsule shell, the fully automatic capsule filling machine can save labor expenses and quickly complete precise and efficient filling.

Features: Suitable for large-scale production and enterprises with high production efficiency and quality requirements.

Clarify production requirements and scale

Matching production volume:

If your daily production is less than 50,000 capsules, a semi-automatic filling machine may be sufficient. For production volumes of more than 100,000 capsules per day, a fully automatic capsule filling machine is recommended for maximum efficiency.

Specification compatibility:

It is very important to choose a machine that is compatible with various capsule sizes, usually from 00# to 4#. Capsule filling machines with good compatibility can adapt to different types and specifications of capsule shells and materials with different characteristics, improving the utilization rate of the equipment. For example, semi-automatic capsule machines or fully automatic capsule machines can be compatible with capsule shells of different sizes by replacing molds, and can adapt to 000#-5# hollow capsules.

Pay attention to the quality and performance of capsule filling machines

When selecting a capsule filling machine, you should consider the machine's quality and performance because these factors have a direct impact on the product's quality and production efficiency. By learning about the capsule filling machine's brand, reputation, after-sales service, etc., you can gauge its quality and performance.

In addition, you can also ask the supplier to provide relevant information and certification documents of the capsule filling machine, such as product quality certification, production license, etc. At the same time, you can visit the supplier's production site to understand the production process and quality control of the capsule filling machine.

Consider the price and cost performance of the capsule filling machine

The prices of capsule filling machines of different brands and models may vary, so it is necessary to choose a suitable capsule filling machine based on the company's budget.

SED PHARMA Capsule Filling Machines

The capsule filling machines produced by SED Pharma are designed for filling powders, granules, or liquids into empty capsules. They use precision mechanical and pneumatic systems, accurate sensors, and easy-to-use controls to deliver optimal results.

SED-BJ Semi-Automatic Capsule Filling Machine

Features：

• Economical and practical: Compared with fully automatic equipment, it has a lower cost and is suitable for use by small and medium-sized enterprises.
• Easy to operate: No complex training is required for operation.
• High flexibility: The filling volume and speed can be adjusted according to production needs.
• Easy maintenance: The structure is relatively simple, which is convenient for daily maintenance and cleaning.
• Wide range of application: Suitable for various types of capsule filling.

Application areas:

• Pharmaceutical industry: used for the production of capsule drugs.
• Health care products industry: used for filling vitamins, minerals and other health supplements.
• Research institutions: used for laboratory sample preparation.

SED-J Fully Automatic Capsule Filling Machine

Features:

• Compact structure, small size, low noise, and precise filling dose.
• Complete functionality and stable operation.
• Capable of completing operations such as capsule loading, separation, filling, waste rejection, locking, finished product discharge, and module cleaning.
• The most ideal hard capsule filling equipment for pharmaceutical, health product, and other manufacturing industries.

SED-YJ Fully Automatic Capsule Liquid Filling Machine

Features:

• Adopts stepless frequency conversion speed regulation, and has the functions of accurate metering, fiber detection, automatic rejection, etc.
• Can fill solutions, suspensions, and microemulsions into hard capsules.
• The latest filling equipment for the development of high-end products in the pharmaceutical, health care and other industries.

Price Range:

The price depends on the model and level of equipment. For more specific price information, it is best to contact SED Pharma directly.

Harro Höfliger

• F 300 Capsule Filling Machine: Equipped with advanced automated control system, used for filling powders, granules and small pellets, 10,000 to 30,000 capsules/hour, suitable for small and medium-sized enterprises. Price is about $100,000 - $150,000.

• F 500 Capsule Filling Machine: With intelligent control system, it can provide detailed production data and traceability, support various types of capsules, and can fill up to 100,000 capsules per hour. It is suitable for large-scale production, especially for pharmaceutical companies that require high output and continuous operation. The price is about $350,000 - $450,000.

• F 800 Capsule Filling Machine: With built-in advanced quality control and inspection systems, it can produce more than 120,000 capsules per hour. It is suitable for large pharmaceutical factories and enterprises that require extremely high output and flexible configuration. The price is about $500,000 or more.

IMA Pharma

• IMA C70 Capsule Filling Machine: Equipped with advanced operating system, suitable for filling powders, granules, and mixtures of granules and powders. The capacity is about 30,000-70,000 capsules per hour, suitable for small and medium-sized enterprises. The price is about US$100,000-200,000.

• IMA NC100 Capsule Filling Machine:Equipped with multiple safety mechanisms, used to fill various types of drugs, including powders, granules, etc., 70,000-100,000 capsules/hour, suitable for medium-sized pharmaceutical companies. The price is about US$150,000-300,000.

• IMA C300 Capsule Filling Machine: Equipped with automatic cleaning system, it can handle different types of capsule sizes, up to 100,000-300,000 capsules/hour, suitable for large-scale production. The price is about US$250,000-450,000.

ACG Worldwide

• ACG PF 100 Capsule Filling Machine: Suitable for most common hard capsules, up to 40,000 - 60,000 capsules/hour. Price is approximately $75,000 - $150,000, depending on the configuration and features selected.

• ACG 4500 Capsule Filling Machine: Suitable for various capsule sizes and types (such as hard capsules, vegetable capsules, etc.), 50,000 - 70,000 capsules/hour, suitable for medium and large enterprises. The price is about $120,000 - $180,000.

• ACG 6000 Capsule Filling Machine: Efficient, precise, and suitable for large-scale production needs, with advanced automation technology, it can fill about 100,000 capsules per hour. The price is about $150,000 - $250,000.

Capsugel

• GKF 1505 Capsule Filling Machine: Fills up to 92,000 capsules per hour and is suitable for the production of conventional capsule sizes. Pricing is based on model, configuration and production capacity.

• GKF 3005 Capsule Filling Machine: Suitable for pharmaceutical, nutritional, viscous and fine powder production. It can produce up to 176,000 capsules per hour to meet large-scale production needs. Pricing is based on model, configuration and production capacity.

• GKF 6005 Capsule Filling Machine: With an output of up to 360,000 capsules per hour, it can meet the needs of large-scale production. Pricing is based on model, configuration and production capacity.

Conclusion

It is well known that choosing the right capsule filling machine is a key factor in achieving business success. The right equipment can not only improve production efficiency and reduce costs, but also ensure the stability and consistency of product quality. In the pharmaceutical industry, high-performance and precise capsule filling machines help optimize production processes, comply with strict regulatory requirements, and build customer trust in your products. If you have any questions or need more information, please feel free to contact SED Pharma's sales manager, we will be happy to serve you.
