Cartoner Packaging Machine
General Description of Cartoner Packaging Machine
This model is a fully automatic high-speed continuous cartoning machine, which is a high-performance product integrating pneumatic, photoelectric and mechanical.
It is suitable for automatically inserting ALU-PVC blister, bottle, hose, soft AL/AL strip and small bag into carton, and can also be connected with supporting machine to form a production line
product Show of Cartoner Packaging Machine
Technical Data
Item | Parameters | |
speed | 200box/min | |
Carton | Grammage | Between 250-350g/m2 |
Size | （78-150）mm×（33-70）mm×（15-60）mm | |
Instructions | Grammage | Between( 50-70)g/m2 |
Size range | (130-160) ×(100-130)mm (L×W) | |
Fold range | (1-4 )fold | |
Air Compressor | Compressed Air Pressure | ≥0.6mpa |
Air consumption | ≥0.3m³/min | |
Standard power supply | 380V 50HZ | |
Power consumption in KW | 1.5 kw | |
Dimensions in mm | 4300㎜×1440㎜×1600㎜ | |
Weight in kg | 1500kg | |
